CURING SYSTEM - Elgi Rubber

System while being vulcanized as well as helping force / secure any repairs tightly against the inside of the casing.
This system has the benefit of being quick and economical -low cost per cure

Available Features	SK 2E
Power Requirement	~1.5KW
Machine Weight	~100 Kg
Tyre Rotation FWD / REV Control	Available
Mono rail Compatibility	Compatible
Tools Tray / Box	Available / Tools Box NA
Flexible Shaft Grinder Compatibility	Available – Optional
Supply Voltage	110-240V 50/60Hz (Based on Customer requirement)
Control Voltage	220V DC
Air Pressure Requirement	NA
Minimum Tyre Size	6.50 – 14
Maximum Tyre Size	12.00 – 24.5
Machine Dimension – LxWxH	~900 x 750 x 2850
Installation	Grouting Recomended

System can be used for both Radial and Bias casings and provides pressure against internal repairs.

Available Features	SK 2E
Power Requirement	~1.5KW
Machine Weight	~100 Kg
Tyre Rotation FWD / REV Control	Available
Mono rail Compatibility	Compatible
Tools Tray / Box	Available / Tools Box NA
Flexible Shaft Grinder Compatibility	Available – Optional
Supply Voltage	110-240V 50/60Hz (Based on Customer requirement)
Control Voltage	220V DC
Air Pressure Requirement	NA
Minimum Tyre Size	6.50 – 14
Maximum Tyre Size	12.00 – 24.5
Machine Dimension – LxWxH	~900 x 750 x 2850
Installation	Grouting Recomended

Catalogue No.	Description	OD (inch)	Section width (inch)	Bead to Bead (inch)	Quantity (per box)
DM31 UX* – 2	2906 – 24	29	06	24	2
DM32 UX* – 2	2906 – 21	29	06	21	2
DM34 UX* – 2	2906 – 19	29	06	19	2
DM60 UX* – 2	3206 – 26	32	06	26	2
DM61 UX* – 2	3206 – 23	32	06	23	2
DM62 UX* – 2	3206 – 21	32	06	21	2
DM63 UX* – 2	3206 – 19	32	06	19	2
DM75 UX* – 2	3507 – 29	35	07	29	2
DM76 UX* – 2	3507 – 26	35	07	26	2
DM77 UX* – 2	3507 – 23	35	07	23	2
DM80 UX* – 2	3807 – 30	38	07	30	2
DM81 UX* – 2	3807 – 25	38	07	25	2
DM82 UX* – 2	3807 – 22	38	07	22	2
DN03 UX* – 2	4008 – 32	40	08	32	2
DN05 UX* – 2	4008 – 27	40	08	27	2
DN08 UX* – 2	4008 – 22	40	08	22	2
DN09 UX* – 2	4010 – 34	40	10	34	2
DN23 UX* – 2	4208 – 28	42	08	28	2
DN24 UX* – 2	4208 – 25	42	08	25	2
DN30 UX* – 2	4210 – 36	42	10	36	2
DN31 UX* – 2	4210 – 34	42	10	34	2
DN32 UX* – 2	4210 – 32	42	10	32	2
DN33 UX* – 2	4210 – 30	42	10	30	2
DN46 UX* – 2	4410 – 36	40	10	36	2
DN47 UX* – 2	4410 – 34	40	10	34	2
DN48 UX* – 2	4410 – 31	40	10	31	2
DN49 UX* – 2	4410 – 29	40	10	29	2
DN50 UX* – 2	4410 – 28	40	10	28	2
DN55 UX* – 2	4412 – 38	40	12	38	2
DN56 UX* – 2	4412 – 36	40	12	36	2
DN57 UX* – 2	4412 – 34	40	12	34	2
DN58 UX* – 2	4412 – 32	40	12	32	2
DN59 UX* – 2	4412 – 30	40	12	30	2
DN65 UX* – 2	4513 – 44	45	13	44	2
DN66 UX* – 2	4513 – 43	45	13	43	2
DN67 UX* – 2	4513 – 37	45	13	37	2
DN68 UX* – 2	4513 – 35	45	13	35	2
DN69 UX* – 2	4513 – 33	45	13	33	2

Catalogue No.	Description	OD (inch)	Section width (inch)	ID (inch)	Quantity (per box)
DP18 – 1	3508 – 22.5*	35	8	22.5	1
DP19 – 1	3808 – 20	38	8	20	1
DP20 – 1	3808 – 22.5	38	8	22.5	1
DP21 – 1	3808 – 24.5	38	8	24.5	1
DP24 – 1	4008 – 22.5	40	8	22.5	1
DP25 – 1	4008 – 24.5*	40	8	24.5	1
